    8TPI 16UN UNC UNF Duplex Stainless Steel Fasteners Bolt Nut Washer M6 - M100 Size

    Ask Lasest Price
    Brand Name : HT
    Model Number : 8TPI 16UN UNC UNF stainless steel bolt nut washer fasteners
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C,T/T, Western Union
    Supply Ability : 1000 set per month
    Delivery Time : 30-35 work days
    • Product Details
    • Company Profile

    8TPI 16UN UNC UNF Duplex Stainless Steel Fasteners Bolt Nut Washer M6 - M100 Size

    8TPI 16UN UNC UNF Duplex Stainless Steel Fasteners Bolt Nut Washer M6 - M100 Size


    1. Carbon steel is categorized by the amount of carbon in the alloy, which impacts the properties of the steel. Low carbon steel, with 0.05-0.3% carbon, is ductile and malleable. It has low tensile strength and can be hardened through carbonizing. It is the least expense of the carbon steel alloys.

    Medium carbon steel has 0.3-0.59% carbon, which provides the alloy with increased strength and good ware resistance. It is easy to machine and is used for forged and automotive parts.

    High carbon steel and ultra-high carbon steel is very strong and is used for springs and high-strength products. These alloys can be tempered to very high hardness without brittleness, and are used for very high wear applications. These alloys have carbon from 0.6-0.99% for high carbon steel and 1.0-2.0% for ultra-high carbon steel.


    2. Carbon steel bolt nut washer Size list

    MaterialSizeLengthStrength Class
    Hexagon Socket Head BoltSCM435M2~M83~50mm12.9
    XM-7M2~M63~50mmA2-70
    Hexagon Socket Countersunk BoltSCM435M3~M88~50mm10.9
    XM-7M3~M88~50mmA2
    Hexagon Socket Button Head BoltSCM435M3~M86~50mm10.9
    XM-7M3~M86~50mmA2

    3.Carbon Steel Bolt Grade Markings


    In addition to the the indicated grade marking, all grades included in this table must be marked for manufacturer identification. While hex heads are shown, grade markings apply equally to products with other head configurations.


    SpecificationMaterialNominal Size
    (inch)
    Proof Load Stress
    (ksi)
    Tensile Strength
    (min ksi)
    Rockwell Hardness
    (min)
    Rockwell Hardness
    (max)
    See Note
    SAE J429 – Grade 2Low or Medium Carbon Steel1/4 thru 3/45574B80B100
    over 3/4 thru 1-1/23360B70B100
    ASTM A307 – Grade ALow or Medium Carbon Steel1/4 thru 460B69B100
    ASTM A307 – Grade BLow or Medium Carbon Steel1/4 thru 460 min
    100 max
    B69B95
    SAE J429 – Grade 5Medium Carbon Steel, Quenched and Tempered1/4 thru 185120C25C34
    ASTM A449 – Type 1Medium Carbon Steel, Quenched and Temperedover 1 thru 1-1/274105C19C30
    over 1-1/2 thru 35590183235NOTE
    ASTM A325 – Type 1Medium Carbon Steel, Quenched and Tempered1/2 thru 185120C24C35NOTE
    over 1 to 1-1/274105C19C31NOTE
    ASTM A325 – Type 3Atmospheric Corrosion Resistant Steel, Quenched and Tempered1/2 thru 185120C24C35NOTE
    over 1 to 1-1/274105C19C31NOTE
    ASTM A354 – Grade BCMedium Carbon Alloy Steel, Quenched and Tempered1/4 thru 2-1/2105125C26C36
    over 2-1/2 thru 495115C22C33
    SAE J429 – Grade 8Medium Carbon Alloy Steel, Quenched and Tempered1/4 thru 1-1/2120150C33C39
    ASTM A354 – Grade BD

    Medium Carbon Alloy Steel, Quenched and Tempered


    1/4 thru 2-1/2120150C33C39NOTE
    over 2-1/2 thru 4105140C31C39NOTE
    ASTM A490 – Type 1Medium Carbon Alloy Steel, Quenched and Tempered1/2 thru 1-1/2120150 min
    170 max
    C33C38
    ASTM A490 – Type 3Atmospheric Corrosion Resistant Steel, Quenched and Tempered1/2 thru 1-1/2120150 min
    170 max
    C33C38NOTE

    4. Carbon steel bolt nut washer surface-black:
